It solves industry pain points such as heat loss, excessive noise, and risk of burns for heavy equipment in manufacturing workshops, and is suitable for all types of industrial equipment such as injection molding, die-casting, generator sets, and compressors.
●Heavy production equipment: Injection molding machines, die-casting machines, fans, and generator sets are laid closely together to block heat radiation from the equipment, reduce the ambient temperature of the workshop, and absorb the roaring noise of equipment operation.
●Closed equipment room: Industrial control cabinets, HVAC units, and heat exchange equipment are internally filled, taking into account the triple protection of heat insulation, sound absorption, and flame retardancy, extending the service life of equipment and reducing operation and maintenance costs.
Technical parameters
performance dimension | Core parameters | illustrate |
Sound absorption and noise reduction | NRC ≥ 0.85 | Broadband and efficient sound absorption, opening rate 99.9% |
Thermal insulation | Thermal conductivity 0.035 W/(m·K) Airgel model≤0.015 W/(m·K) | Better than traditional rock wool/glass wool |
Flame retardant safety | UL94 V-0 /B1 level | Intrinsically flame retardant, self-extinguishing when removed from fire, no droplets and low smoke |
Lightweight | Density 8-12 kg/m³ | 5-10 times lighter than traditional materials, reducing structural load |
Temperature resistance range | -160℃ ~ +240℃ | Stable performance in extreme temperature environments |
Environmental protection and safety | RoHS/REACH certified, zero formaldehyde | No dust, no irritation, safe and environmentally friendly |
